Chapter 1. Product composition and interface definition:
- Product Overview
Product name: Satellite communication intelligent management terminal
Model: YT-S9
Product specification: L282mm * W125mm * H41mm
GTS08 Woopker V8 Finder2 DVB-S2 No ne satellite positioSatellite Finder Digital Signal Detector Receiver LCD Screen for Adjusting Sat
$399.00
- Product complete machine parameter table
Serial number
project
Specifications
remark
1
Charging voltage
DC5V ～ 6V
2
Satellite
operating current
<600mA
3
4G working current
<100mA
3
Standby current
<200uA
4
Specifications
282*125*41mm
5
Targeting method
GPS+Beidou+LBS
6
Body color
grey
7
Communication
networks
4G
LTE-FDD:
B1/B2/B3/B4/B5/B7/B8/B12/B13/
B18/B19/
B20/B25/B26/B28/B66
LTE-TDD:B38/B39/B40/B41
GSM:850/900/1800/1900
8
Satellite
communications
Inmarsat GEO
Bidirectional communication
Global coverage, low power
consumption,
low
latency,
multi frequency band
L Band：
Frequency
of
sending
：
1626.5~1660.5 MHz ； 1668~1675
MHz
Reception
frequency
：
1518.0~1559.0 MH
9
Methods
of
Communication
TCP/UDP
